Toyota Avalon (XX50) 2019-2022 Service & Repair Manual > Camshaft: Installation
INSTALLATION PROCEDURE 1. SET NO. 1 CYLINDER TO TDC (COMPRESSION) (a) Confirm that the timing mark (cutout) on the crankshaft pulley is aligned with the "0" timing mark of the timing chain cover assembly. *a Timing Mark (Cutout) *b "0" Timing Mark 2. SET CAMSHAFT TIMING GEAR ASSEMBLY (for Bank 2) HI ...
