INSTALLATION PROCEDURE 1. INSTALL AUTO HIGH BEAM SWITCH (a) Engage the 2 claws to install the auto high beam switch as shown in the illustration.
2. INSTALL NO. 1 INSTRUMENT PANEL SUB-ASSEMBLY Click here 3. CONNECT HOOD LOCK CONTROL LEVER SUB-ASSEMBLY Click here 4. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY Click here 5. INSTALL INSTRUMENT SIDE PANEL LH Click here 6. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH Click here 7. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH Click here 8. INSTALL FRONT DOOR SCUFF PLATE LH Click here |
